4 On the Connection tab, set the R
and click OK. A value of 10.0 ms or more is recommended.
The MVI69E-MBS module is now visible in the I/O Configuration tree.
2.2

Installing ProSoft Configuration Builder

Use the ProSoft Configuration Builder (PCB) software to configure the module. You can
find the latest version of the ProSoft Configuration Builder (PCB) on our web site:
www.prosoft-technology.com. The installation filename contains the PCB version
number. For example, PCB_4.3.4.5.0238.
Installing PCB from the ProSoft website:
1 Open a browser window and navigate to
2 Navigate to the ProSoft Configuration Builder download link, and save the file to your
Windows desktop.
3 After the download completes, double-click the file to install. If you are using
Windows 7, right-click the PCB installation file and then choose R
A
DMINISTRATOR
4 If you want to find additional software specific to your MVI69E-MBS, enter the model
number into the ProSoft website search box and press the Enter key.
ProSoft Technology, Inc.
EQUESTED
. Follow the instructions that appear on the screen.
P I
ACKET NTERVAL
.
EXE
www.prosoft-technology.com
Configuring the Module in RSLogix
User Manual
value for your project
UN AS
