MVI69E-MBS ♦ CompactLogix™ Platform
Modbus Serial Enhanced Communication Module
Additional Configuration Parameters as Slave
The Type parameter must be S
See Configuration Parameters Common to Master and Slave (page 40).
Parameter
Minimum
Response Delay
Internal Slave ID
Bit Input Offset
Word Input Offset 0 to 9998
Output Offset
Holding Register
Offset
ProSoft Technology, Inc.
or P
LAVE
Description
Value
0 to 65535 Sets the number of milliseconds to wait before responding to a
milliseconds command received on the port from a remote Master. This
delay is sometimes required to accommodate slower Master
devices.
1 to 247 Defines the Slave Node Address for the internal database. All
requests received by the port with this address are processed
by the module. Verify that each device has a unique address
on a network.
0 to 9999 Specifies the offset address into the internal Modbus database
for network requests for Modbus function 2 commands. For
example, if you set the value to 150, an address request of 0
returns the value at register 150 in the database.
Specifies the offset address into the internal Modbus database
for network requests for Modbus function 4 commands. For
example, if you set the value to 150, an address request of 0
returns the value at register 150 in the database.
0 to 9998 Specifies the offset address into the internal Modbus database
for network requests for Modbus function 1, 5 or 15
commands. For example, if you set the value to 100, an
address request of 0 corresponds to register 100 in the
database.
0 to 9998 Specifies the offset address in the internal Modbus database
for network requests for Modbus function 3, 6, or 16
commands. For example, if you set the value to 50, a request
for address 0 corresponds to the register 50 in the database.
Configuring the MVI69E-MBS Using PCB
T S to configure these parameters.
ASS HRU LAVE
