MVI69E-MBS ♦ CompactLogix™ Platform
Modbus Serial Enhanced Communication Module
MBS.CONTROL.EventCmd_ProcessorData
This array allows the processor to dynamically build Modbus commands with processor
data. This feature is meant for periodic execution such as resetting the clock and
zeroing-out counters.
Tag Name
MBS.CONTROL.EventCmd_Processor
Data.CmdTrigger
MBS.CONTROL.EventCmd_Processor
Data.GetStatusTrigger
MBS.CONTROL.EventCmd_Processor
Data.PortNumber
MBS.CONTROL.EventCmd_Processor
Data.SlaveAddress
MBS.CONTROL.EventCmd_Processor
Data.ModbusFunctionCode
MBS.CONTROL.EventCmd_Processor
Data.DeviceDBAddress
MBS.CONTROL.EventCmd_Processor
Data.PointCount
MBS.CONTROL.EventCmd_Processor
Data.Data[x]
MBS.CONTROL.EventCmd_Processor
Data.EventCmdStatusReturned
MBS.CONTROL.EventCmd_Processor
Data.PortxStatus
MBS.CONTROL.EventCmd_Processor
Data.PortxStatus.Status
MBS.CONTROL.EventCmd_Processor
Data.PortxStatus.LastError
ProSoft Technology, Inc.
Description
Range
0 or 1 Toggle to send Event Command.
0 = Disable, 1 = Enable
0 or 1 Toggle to retrieve event status.
0 = Disable, 1 = Enable
1 or 2 Port number to be associated with
command
1 to 248 Slave ID of Modbus slave
- Modbus function code (5,6,15, or 16)
0 to 9999 Modbus address of the target slave
database
0 to 125 Number of bit/words associated with this
command.
0 to 49 Data values to be sent to the slave
- Command status
Port x Status array
-
- Status code. See Communication Error
Codes (page 110).
- Last error code
Using Controller Tags
