8.4.6 Add Event with Data Blocks (8000, 8001)

Block 8000: Add Event with Data for Port 1
Block 8001: Add Event with Data for Port 2
The 8000-series blocks are similar to the 1000 and 2000-series blocks. The 8000-series
blocks source the command data from the processor, instead of from the module's
database.
Block 8000 or 8001: Request from Processor to Module
Description
Offset
Write Block ID: 8000 for Port 1 or 8001 for Port 2 event command with data
0
request
Slave address of Modbus device to reach with the command request
1
Modbus function code to use with command (5, 6, 15 or 16)
2
Modbus address in slave device
3
Count value for operation- bit count for function 15 (1 to 800 points) and word
4
count for function 16 (1 to 50 words or 1 to 25 float values). For functions 5 and 6,
the count is assumed to be 1.
Data to be used by command
5 to 54
Spare
55 to (n-1)
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
Block 8000 or 8001: Response from Module to Processor
Description
Offset
Read Block ID: 8000 for Port 1 or 8001 for Port 2 event command with data request
0
Write Block ID: To be used by the processor in its next Write block.
1
Error Code for request:
2
0=no error
-1=port is not enabled
-2=port is not a master port
-3=port is not active (enabled)
-4=port busy with previous event command
-5=invalid Modbus command
-6=invalid point count for command
Spare
3 to (n-1)
