MVI69E-MBS ♦ CompactLogix™ Platform
Modbus Serial Enhanced Communication Module
MBS.CONTROL.Time
This array allows the processor to get or set module time.
Tag Name
SetTime
GetTime
Year
Month
Day
Hour
Minute
Second
Milliseconds
MBS.CONTROL.GetStatus
This tag allows the processor to retrieve status from the module.
Tag Name
GetStatus
MBS.CONTROL.ResetStatus
This tag allows the processor to reset the module status counters.
Tag Name
ResetStatus
MBS.CONTROL.ColdBoot
This tag allows the processor to Coldboot the module (full reboot).
Tag Name
ColdBoot
MBS.CONTROL.WarmBoot
This tag allows the processor to Warmboot the module (driver reboot).
Tag Name
WarmBoot
ProSoft Technology, Inc.
Description
Range
0 or 1 Sends the PLC time to the module
0 = Disable, 1 = Enable
0 or 1 Retrieves the time from the module to PLC
0 = Disable, 1 = Enable
0 to 9999 Four digit year value. Example: 2015
1 to 12 Month
1 to 31 Day
Hour
0 to 23
0 to 59 Minute
0 to 59 Second
0 to 999 Millisecond
Description
Range
0 or 1 Triggers status retrieval from the module
0 = Disable, 1 = Enable
Description
Range
0 or 1 Triggers module status counter reset
0 = Disable, 1 = Enable
Description
Range
0 or 1 Triggers a cold boot of the module
0 = Disable, 1 = Enable
Description
Range
0 or 1 Triggers a warm boot the module
0 = Disable, 1 = Enable
Using Controller Tags
