4.3.3 MBS.CONTROL

This array handles special tasks requested by the processor.
MBS.CONTROL.PortControl
This array allows port commands to be controlled by the processor.
Tag Name
MBS.CONTROL.PortControl.
Set
MBS.CONTROL.PortControl.
Get
MBS.CONTROL.PortControl.
Portx
MBS.CONTROL.PortControl.
Portx.Active
MBS.CONTROL.PortControl.
Portx.CmdEnableBits[x]
MBS.CONTROL.CmdControl
This array allows the processor to dynamically enable configured commands for
execution.
Tag Name
MBS.CONTROL.CmdControl.
CmdControlTrigger
MBS.CONTROL.CmdControl.
NumberOfCommands
MBS.CONTROL.CmdControl.
PortNumber
MBS.CONTROL.CmdControl.
CommandIndex[x]
ProSoft Technology, Inc.
Description
Range
0 or 1 Sends Port Control to module
0 or 1 Reads Port Control from module
n/a Definition of Port x Control
0 or 1 Port Control: Disable = 0, Enable = 1
0 or 1 Index of command to be controlled. Example:
Command 20 in port 1 command list can be
controlled at CmdEnableBits[1].3. This is the 20
offset.
Description
Range
0 or 1 One-shot command control:
Disable = 0, Enable = 1
0 to 6 Total number of commands to be executed via
Command Control
1 or 2 Port number to be associated with Command Control
function
0 or 249 Command Index of port command [x] to be enabled.
Up to 6 command indexes can be populated at a
time.
