MBS.CONTROL.EventCmd_DBData
This array allows the processor to dynamically build Modbus commands with data
associated to the MBS database. This feature is meant for periodic execution such as
resetting the clock and zeroing-out counters.
Tag Name
MBS.CONTROL.EventCmd_DB
Data.EventCmdTrigger
MBS.CONTROL.EventCmd_DB
Data.PortNumber
MBS.CONTROL.EventCmd_DB
Data.SlaveID
MBS.CONTROL.EventCmd_DB
Data.InternalDBAddress
MBS.CONTROL.EventCmd_DB
Data.PointCount
MBS.CONTROL.EventCmd_DB
Data.SwapCode
MBS.CONTROL.EventCmd_DB
Data.ModbusFunctionCode
MBS.CONTROL.EventCmd_DB
Data.DeviceDBAddress
MBS.CONTROL.EventCmd_DB
Data.EventCmdStatusReturned
ProSoft Technology, Inc.
Description
Range
0 or 1 Toggle to send Event Command.
0 = Disable, 1 = Enable
1 or 2 Port number to be associated with command Control
function
1 to 248 Slave ID of Modbus slave
0 to 9999 Used only if UseModuleDBAddress=1. MVI69E
database address (word address for functions
3,4,6,16 and bit address for 1,2,5,15)
0 to 125 Number of bit/words associated with this command.
0 to 3 Swap code 0 = no swap, 1 = word swap, 2 = words
& byte swap, 3 = byte swap
- Modbus function code (1,2,3,4,5,6,15, or 16)
0 to 9999 Modbus address of the target slave database
Event status returned by the module
-
