4.3.4 MBS.STATUS

This array contains status data for the module.
Tag Name
MBS.STATUS.PassCnt
MBS.STATUS.Product
MBS.STATUS.Rev
MBS.STATUS.OP
MBS.STATUS.Run
MBS.STATUS.PortxStats
MBS.STATUS.PortxStats.CmdListReq
MBS.STATUS.PortxStats.CmdListResp
MBS.STATUS.PortxStats.CmdListErr
MBS.STATUS.PortxStats.PortReq
MBS.STATUS.PortxStats.PortResp
MBS.STATUS.PortxStats.PortErrSent
MBS.STATUS.PortxStats.PortErrRec
MBS.STATUS.PortxStats.CurrErr
MBS.STATUS.PortxStats.LastErr
MBS.STATUS.Block
MBS.STATUS.Block.Read
MBS.STATUS.Block.Write
MBS.STATUS.Block.Parse
MBS.STATUS.Block.Event
MBS.STATUS.Block.Cmd
MBS.STATUS.Block.Err
MBS.STATUS.PortxLastErr
MBS.STATUS.PortxPreviousErr
ProSoft Technology, Inc.
Description
Program cycle counter – this value is incremented each
time a complete program cycle occurs in the module
Product code
Firmware revision level number
Operating level number
Run number
Port x status
Total number of requests made from this port to slave
devices on the network
Total number of slave response messages received on
the port
Total number of command errors processed on the port.
These errors could be due to a bad response or
command
Total number of messages sent out of the port
Total number of messages received on the port
Total number of message errors sent out of the port.
Total number of message errors received on the port
Not used
Not used
Backplane transfer status
Total number of read blocks transferred from the module
to the processor
Total number of write blocks transferred from the
processor to the module
Total number of blocks successfully parsed that were
received from the processor
Total number of event command blocks received from
the processor
Total number of command blocks received from the
processor
Total number of block transfer errors recognized by the
module
For a slave port, this field contains the value of the
current error code returned.
For a master port, this field contains the index of the
currently executing command.
For a slave port, this field contains the value of the last
error code returned.
For a master port, this field contains the index of the
command with an error.
