8.4.7 Get Event with Data Status Block (8100)

Block 8100: Get Event with Data Status
This block requests status data for Event with Data Commands.
Block 8100: Request from Processor to Module
Description
Offset
Write Block ID: 8100 status data request for Event with Data Commands.
0
Spare
1 to (n-1)
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
Block 8100: Response from Module to Processor
Description
Offset
Read Block ID: 8100 status data for Event with Data Commands.
0
Write Block ID: To be used by the processor in its next Write block.
1
Event command status for Port 1:
2
0=No message active
1=Waiting to execute command
2=Command complete
Error code for last command executed for Port 1
3
Event command status for Port 2:
4
0=No message active
1=Waiting to execute command
2=Command complete
Error code for last command executed for Port 2
5
Spare
6 to (n-1)
