MVI56E-SMGC ♦ ControlLogix™ Platform
Enhanced FMC722 TPU General Communication Module

2 MVI56E-SMGC Configuration

2.1 Using ProSoft Configuration Builder Software

ProSoft Configuration Builder (PCB) provides a quick and easy way to manage module
configuration files customized to meet your application needs. PCB is not only a
powerful solution for new configuration files, but also allows you to import information
from previously installed (known working) configurations to new projects.
Note: During startup and initialization, the MVI56E-SMGC module receives its protocol and backplane
configuration information from the installed Personality Module (Compact Flash). Use ProSoft Configuration
Builder to configure module settings and to download changes to the Personality Module.

2.1.1 Installing ProSoft Configuration Builder

Use the ProSoft Configuration Builder (PCB) software to configure the module. You can
find the latest version of the ProSoft Configuration Builder (PCB) on our web site:
www.prosoft-technology.com. The installation filename contains the PCB version
number. For example, PCB_4.3.4.5.0238.
1 Open a browser window and navigate to www.prosoft-technology.com.
2 Perform a search for 'pcb' in the Search bar. Click on the ProSoft Configuration
Builder search result.
3 On the PCB page, click the download link for ProSoft Configuration Builder, and save
the file to your Windows desktop.
4 After the download completes, double-click the file to install. If you are using
Windows 7, right-click the PCB installation file and then choose R
A
DMINISTRATOR
5 If you want to find additional software specific to your MVI56E-SMGC, enter the
model number into the ProSoft website search box and press the E
ProSoft Technology, Inc.
. Follow the instructions that appear on the screen.
.
EXE
MVI56E-SMGC Configuration
User Manual
UN AS
key.
NTER
Page 19 of 98
