7.6.4 Port x Module Information

The MODBUS PORT 1 and MODBUS PORT 2 menus include the following submenus:

Configuration

Status (General status for the port)

Master Commands (Used when port is configured as a Modbus master)

Slave Status List (Status of each slave on the network, used when port is configured
as a Modbus master)

Master Command Status (Status code for each master command, used when port is
configured as a Modbus master)
