All data transferred between the module and the processor over the backplane is
through the input and output images. Ladder logic in the CompactLogix or MicroLogix
1500-LRP processor interfaces the input and output image data with data defined in the
Controller Tags. All data used by the module is stored in its internal database. This
database is defined as virtual MBS data tables with addresses from 0 to the maximum
number of points for each data type.
5.3

Normal Data Transfer

5.3.1 Write Block: Request from the Processor to the Module

These blocks of data transfer information from the processor to the module. The
structure of the output image used to transfer this data is shown below:
Offset
0
1 to (n)
(n) = 60, 120, or 240 depending on the Block Transfer Size parameter (refer to the configuration file).
The Write Block ID is an index value that determines the location in the module's
database where the data is placed.

5.3.2 Read Block: Response from the Module to the Processor

These blocks of data transfer information from the module to the processor. The
structure of the input image used to transfer this data is shown below:
Offset
0
1
2 to (n+1)
(n) = 60, 120, or 240 depending on the Block Transfer Size parameter (refer to the configuration file).
