Introduction

This manual is intended for use by service technicians responsible for installing and servicing 682 digital weight indicators.
Configuration and calibration of the indicator can be accomplished using the Revolution
front panel keys. See Section 4.0 on page 29
Manuals and additional resources are available from Rice Lake Weighing Systems at
Warranty information can be found on the website at
1.1

Safety

Safety Signal Definitions:
DANGER: Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
CAUTION: Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
IMPORTANT: Indicates information about procedures that, if not observed, could result in damage to equipment or
corruption to and loss of data.
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
Some procedures described in this manual require work inside the indicator enclosure. These procedures are to be performed by
qualified service personnel only.
Do not allow minors (children) or inexperienced persons to operate this unit.
Do not operate without the enclosure completely assembled.
Do not place fingers into slots or possible pinch points.
Do not use this product if any of the components are cracked.
Do not make alterations or modifications to the unit.
Do not remove or obscure warning labels.
Do not submerge.
Do not use solvents or aggressive substances to clean the indicator.
Do not exceed the rated specification of the unit.
Only connect unit to equipment certified to IEC 60950, IEC 62368, IEC 61010 or similar.
Do not use for purposes other than weight taking.
Before opening the unit, ensure the power cord is disconnected from the power source.
Disconnect all power before servicing. Multiple power sources may be present. Failure to do so may cause property damage,
personal injury or death.
For permanently connected equipment, a readily accessible disconnect device shall be incorporated in the building installation
wiring.
Pluggable units must be installed near the socket/outlet and be easily accessible.
Use copper or copper-clad aluminum conductors only.
and Section 6.0 on page 56
