Rice Lake REVOLUTION 682 Synergy Plus Technical Manual page 41

Menu
Zero Range (%) The total amount the scale can be zeroed; Zero range represents a percentage of capacity; The default value of 1.9
represents ±1.9% around the calibrated zero point, for a total range of 3.8%; A value of 0.0 prevents zeroing; Maximum legal
value depends on local regulations; Enter value: 0.0–100.0, 1.9 (default)
Initial Zero Range When the indicator is turned on and the weight value is between the ± percent range specified by Calibrated Zero, the
(%) indicator automatically zeros off the weight; Enter value: 0.0–100.0, 0.0 (default)
Motion Band Sets the level, in display divisions, at which scale motion is detected; If motion is not detected for the time defined by Standstill
Time, the standstill symbol lights; Some operations, including print, tare and zero, require the scale to be at standstill;
Maximum legal value varies depending on local regulations; If this parameter is set to 0, the standstill annunciator is always lit
and operations requiring standstill are performed regardless of scale motion; If 0 is selected, Zero Track Band must also be
set to 0; Enter value: 0–100, 1 (default)
Overload Determines the point at which the display blanks and the overload error message displays (^^^^^^^); Maximum legal value
varies depending on local regulations; Settings: Full Scale + 2% (default), Full Scale + 1D, Full Scale + 9D, Full Scale
Sample Rate Selects measurement rate, in samples per second, of the analog-to-digital converter; Lower sample rate values provide greater
signal noise immunity; Settings: 6.25HZ, 7.5HZ, 12.5HZ, 15HZ, 25HZ, 30HZ (default), 50HZ, 60HZ, 100HZ, 120HZ
Filter Chain Type Sets the filter type to be used; Settings:
Average Only (default) – Digital Rolling Average Filter
Digital Filter Sensitivity and Digital Filter Threshold
Adaptive Only – Adaptive Filter
Threshold
Damping Only – Damping Filter
Raw – No filtering
Digital Filter Sets the digital filtering rate used to reduce the effects of environmental influences from the immediate area of the scale;
Settings indicate the number of A/D conversions per update which are averaged to obtain the displayed reading; a higher
Stage 1-3
number gives a more accurate display by minimizing the effect of a few noisy readings, but slows down the response time of
the indicator; Settings: 1, 2, 4 (default), 8, 16, 32, 64, 128, 256
Digital Filter Specifies the number of consecutive A/D readings which fall outside the Filter Threshold before filtering is suspended;
Sensitivity Settings: 2OUT (default), 4OUT, 8OUT, 16OUT, 32OUT, 64OUT, 128OUT
Digital Filter Sets a threshold value, in display divisions; when a number of consecutive A/D readings (Digital Filter Sensitivity) falls outside
Threshold of this threshold value (when compared to the output of the filter), filtering is suspended and the A/D value is sent straight
through the filter; Filtering is not suspended if the threshold is set to NONE; Settings: NONE (default), 2D, 5D, 10D, 20D, 50D,
100D, 200D, 250D
Adaptive Filter Controls the stability and response time of the scale; Settings:
Sensitivity
Light (default) – Fastest response to small weight changes, but less stable
Medium – Has a quicker response time than heavy, but more stable than light
Heavy – Results in an output which is more stable but settles slowly; small changes in weight data (a few grads) on the
scale base are not seen quickly
Adaptive Filter Sets the adaptive filter weight threshold value (in display divisions); a weight change exceeding the threshold resets the
Threshold filtered values; must be set above the noise disturbances in the system (if set to zero, the filter is disabled);
Enter value: 0–2000, 10 (default)
Sets the damping time constant (in 0.1 sec intervals); Enter value: 0–2560, 10 (default)
Damping Value
RattleTrap Enables RattleTrap filtering; Effective at eliminating vibration effects, environmental influences and mechanical interference
from nearby machinery, may increase response time over standard digital filtering; Settings: Off (default), On
Tare Function Enables or disables push-button and keyed tare; Settings:
Both (default) – Both push button and keyed tares are enabled
No Tare – No tare allowed (gross mode only)
Push Button Tare – Push button tares enabled
Keyed Tare – Keyed tares enabled
Standstill Time Specifies the length of time the scale must be out of motion, before the scale is considered to be at standstill (in 0.1 sec
intervals); Enter value: 0–600, 10 (default)
Sense Specifies the type of load cell cable connected to the J1 connector
correctly to match the actual load cell cable connection to ensure the load cell functions properly with the indicator;
Settings: 4-WIRE (default), 6-WIRE
Table 4-6. Configuration Menu Descriptions (Continued)
(Section 16.7.2 on page
(Section 16.7.3 on page
© Rice Lake Weighing Systems ● All Rights Reserved
Description
(Section 16.7.1 on page 114); Uses Digital Filter Stage 1-3,
115); Uses Adaptive Filter Sensitivity and Adaptive Filter
115); Uses Damping Value
(Section 2.4.5 on page
Configuration
8); this parameter must be set
33
