10.6.4 Scale Status

12-31
** Center of Zero

10.6.5 Scale Error

NOTE: The scale error bit is always set to 1 unless one of the following errors occurs. At that time, the error bit is set to 0
until the error is cleared.
Table 10-12. Status Descriptions
Bit Description
0 Net Weight Polarity
1 Gross Weight Polarity
2 Weight Stability
3 Underload Condition
4 Overload Condition
5 Push Button Tare Condition
6 Keyed Tare Condition
7 Gross Center of Zero
8 Display Mode
9 Current Units
10 Heartbeat - delay of 500 ms between on and off 0 = Off
11 Scale Error
12 Accumulator Weight Polarity
Future Use
Table 10-13. Error Conditions
Configuration signature error
General configuration checksum error
Load cell data checksum error
Backup battery voltage low
Battery backed memory corrupt
Load cell A/D error
Tare data checksum error
Accumulator overflow error
Unable to write to non-volatile memory
0 = Positive
0 = Stable
0 = OK
0 = OK
0 = No
0 = No
0 = COZ**
0 = Net
0 = Primary
0 = Error
0 = Positive
Error Condition
© Rice Lake Weighing Systems ● All Rights Reserved
Fieldbus Options Configuration
Bit Status
1 = Negative
1 = Motion
1 = Under
1 = Under
1 = Yes
1 = Yes
1 = COZ**
1 = Gross
1 = Other
1 = On
1 = OK
1 = Negative
