Token
Setpoint Tokens
<SCV> Setpoint captured value
<SN> Setpoint number
<SNA> Setpoint name
<SPM> Setpoint mode (gross or net label)
<SPV> Setpoint preact value
<STV> Setpoint target value
Auditing Tokens
<CD> Last calibration date
<NOC> Number of calibrations
<NOW> Number of weighments since last calibration
NOTE: Last calibration date (<CD>) and number of calibrations (<NOC>) are updated anytime a calibration is performed on any of the scales.
Number of weighments (<NOW>) is incremented whenever the scale weight exceeds 10% of scale capacity. Scale must return to gross or net
zero before the value can be incremented again.
Formatting and General-Purpose Tokens
<nnn> ASCII character (nnn = decimal value of ASCII character); used for inserting control
characters (STX, for example) in the print stream
<TI> Time
<DA> Date
<TD> Time and date
<UID> Unit ID number (up to 8 alphanumeric characters)
<CN> Consecutive number (up to 7 digits)
<H1> Insert header format 1 (HDRFMT1), see
<H2> Insert header format 2 (HDRFMT2), see
<CR> Carriage return character
<LF> Line feed character
<NLnn> New line (nn = number of termination (<CR/LF> or <CR>) characters)*
<SPnn> Space (nn = number of spaces)*
<SU> Toggle weight data format (formatted/unformatted)
NOTE: If nn is not specified, 1 is assumed. Value must be in the range 1–99.
User Program-Dependent Tokens
<USnn> Insert user print text string (from user program, SetPrintText API)
Header Format Tokens
<COMP> Company name (up to 30 characters)
<COAR1> Company address, lines 1–3 (up to 30 characters)
<COAR2>
<COAR3>
<CONM1> Company contact names (up to 20 characters)
<CONM2>
<CONM3>
<COPH1> Company contact phone numbers (up to 20 characters)
<COPH2>
<COPH3>
<COML> Company contact e-mail address (up to 30 characters)
Truck Format Tokens
<TID> Truck ID (up to 16 characters)
<TR1> Gross weight for current ticket in displayed units
<TR2> Tare weight (inbound) for current ticket in displayed units
<TR3> Net weight (outbound) for current ticket in displayed units
NOTE: TR1, TR2 and TR3 truck ticket weight data includes keywords INBOUND, KEYED and RECALLED, as needed.
Table 13-1. Print Format Tokens (Continued)
Description
Table 13-2 on page 98
Table 13-2 on page 98
© Rice Lake Weighing Systems ● All Rights Reserved
Print Formatting
Supported Ticket Formats
SPFMT
All
All
All
All
TRFMT, TRWINFMT, TRWOUTFMT
97
