Standard Calibration Process - Rice Lake REVOLUTION 682 Synergy Plus Technical Manual

682 Synergy Plus

10.7 Standard Calibration Process

Refer to Table 10-3 on page 76
commands. See Section 10.6.2 on page 79
calibration process.
The standard calibration process requires access to Setup mode
1. Set Capacity, Units and Format parameter data values
2. Send command 27 to write Capacity, Units and Format parameter data values.
NOTE: No external button presses are needed to put the indicator into calibration mode with command 27 as long as the
Audit Jumper is in the ON position
3. Remove all weight from the scale.
4. Send command 35 to perform a zero calibration.
5. Set the Calibration Weight parameter data value to the needed span weight.
6. Set the Calibration Point parameter data value to 1.
7. Place the specified calibration weight on the scale.
8. Send command 36 to perform a span calibration.
9. Send command 38 to save and exit calibration mode.
82 Visit our website
for parameter data information and
and Section 10.6.3 on page 79
(Section 4.1.1 on page
www.RiceLake.com
Table 10-4 on page 77 for descriptions of calibration
for possible command responses during the
(Section 4.1 on page 29).
(Table 10-3 on page 76).
29).
