Scale Format Menu

This section provides a flow chart and descriptions for the Scale Format menu.
User
Configuration Scale Format
Custom Unit 3
Parameter
Scale format and units settings for the Primary format; Sub-Parameters:
Primary
Format – Sets the decimal point and the display divisions for the Primary display weight format;
Settings: 8888881 (Primary default), 8888882, 8888885, 8888810, 8888820, 8888850, 8888100, 8888200, 8888500,
88.88881, 88.88882, 88.88885, 888.8881, 888.8882, 888.8885, 8888.881, 8888.882, 8888.885, 88888.81, 88888.82,
88888.85, 888888.1, 888888.2, 888888.5
For example, select 8888.885 if a count by of 0.005 is needed or select 8888820 if a count by of 20 is needed
(the 8s serve as placeholders and show a breakdown of how digits will display);
Units – Sets the units type; Settings: LB (Primary default), KG, OZ, TN, T, G, NONE
Split Mode – See
Settings: Off (default), Multi-Range, Multi-Interval
Scale format and units settings for the Secondary and Tertiary format; Sub-Parameters:
Secondary and
Format – Sets the decimal point and the display divisions for the Secondary and Tertiary display weight format;
Tertiary
Settings: 8888881, 8888882, 8888885, 8888810, 8888820, 8888850, 8888100, 8888200, 8888500, 88.88881, 88.88882,
88.88885, 888.8881, 888.8882, 888.8885, 8888.881, 8888.882, 8888.885, 88888.81, 88888.82, 88888.85, 888888.1,
888888.2, 888888.5 (Secondary and Tertiary default)
For example, select 8888.885 if a count by of 0.005 is needed or select 8888820 if a count by of 20 is needed
(the 8s serve as placeholders and show a breakdown of how digits will display);
Units – Sets the units type; Settings: LB, KG (Secondary and Tertiary default), OZ, TN, T, G, NONE
Enabled – Enables the front panel UNITS button to toggle between the Primary, Secondary and Tertiary formats; Only
displays under Secondary and Tertiary; Settings: ON (Secondary default), OFF (Tertiary default)
Available custom units that can be set as the Secondary and Tertiary units to convert weight of the Primary unit; Sub-Parameters:
Custom Unit 1-3
Label – Available to enter a name for custom units; maximum length is 2 alphanumeric characters; blank by default
Multiplier – Conversion factor/multiplier applied to the primary units to convert weight for custom units; 1.0 (default)
For example, to configure a custom unit to gallons (with primary units set to lb), set the custom unit multiplier to 8
34 Visit our website
Figure 4-8. Scale Format Menu
Setup Tare
Calibration
Primary Secondary
Table 4-7. Scale Format Menu Parameters
Section 5.0 on page 54
www.RiceLake.com
Tertiary Custom Unit 1
Description
for more information; Only displays under Primary;
Custom Unit 2 Custom Unit 3
