10.2 682 Fieldbus Configuration

The following procedure details how to configure the 682 for Fieldbus. Once the necessary 682 parameters are configured and
installation complete, communication with the SCT-2200 Fieldbus option (firmware version 1.25 or higher) is ready.
1. Navigate to the Communications menu in Setup mode
2. Press .
Serial
3. Press .
RS-232 Port 1
4. Press or
5. Press .
Trigger
6. Press . The current setting for the RS-485 Trigger is highlighted.
7. Ensure Fieldbus is selected and press
NOTE: The Trigger parameter for the Serial Option Card Port would be set to Fieldbus when using a serial option card.
8. Press twice.
9. Press .
Fieldbus
10. Press .
Network Protocol
11. Press . The current set Network Protocol is highlighted. Select needed protocol and press
12. Press .
Protocol Parameters
13. Press to return to Weigh mode.
If the Fieldbus option is not communicating the correct data, adjust the Byte/Word Swap parameter in the indicator.
See Section 4.5.4.5 on page 41
682 Fieldbus Troubleshooting
After configuring the 682 parameters, cycle power to the module if it is wired to the 682.
The EtherNet/IP, Modbus TCP, PROFINET, DevicNet, and CANopen modules have three status LEDs:
• Green LED = Power — Green Power LED is on when there is power to the module
• Yellow LED = Status — Yellow Status LED is the RS-485 communication to the 682
If the module is not communicating, the yellow LED blinks rapidly for ~15 seconds then turns off for 1 second.
If the module is communicating with the 682, the yellow LED blinks rapidly and does not turn off after ~15 seconds.
• Red LED = Error — Red Error LED blinks until PLC is connected and communicating with the module, then turns off
The PROFIBUS module has four status LEDs that function differently than the above modules:
• Red LED = Power — Red Power LED stays on when there is power to the module
• Yellow LED = PROFIBUS — Yellow PROFIBUS LED stays on once module is connected to the PLC
If the module is not connected to the 682, the Yellow PROFIBUS LED blinks rapidly for ~15 seconds, then the Green
RX LED blinks 3 times, followed by the Yellow TX LED blinking 3 times. This cycle repeats until module connects.
• Green LED = RX — Green RX LED and Yellow TX LED blink alternately when module is communicating with the 682
• Yellow LED = TX — Yellow TX LED and Green RX LED blink alternately when module is communicating with the 682
74 Visit our website
displays.
displays.
until displays.
RS-485
displays.
.
displays.
Serial
displays.
displays.
displays. Edit the protocol specific parameters if necessary.
for the Fieldbus menu structure and parameter descriptions.
www.RiceLake.com
(Section 4.1 on page 29).
Communications
displays.
.
