Rice Lake REVOLUTION 682 Synergy Plus Technical Manual page 73

3. Scan for available Wi-Fi networks using a computer or handheld device and connect to the Soft AP. It might take a few
attempts before the Soft AP appears on the computer or device.The Soft AP only shows up as a 5-GHz network.
• Soft AP Name: RLWS_XXXXXX
• Soft AP Password: PASSWORD
IMPORTANT: It is recommended to change default passwords to limit access and for security.
NOTE: The X's in the name represent the last 6 digits of the Wi-Fi MAC address. The serial number on the wireless module's
label is almost the same, other than the last digit being one number/character less than the Wi-Fi MAC address.
FOR EXAMPLE: If the module's serial number is "0080A3E8C27A", then the SSID would be "RLWS_E8C27B". The MAC
address is a Hexadecimal value, so the letter A follows the number 9, and this continues to F before incrementing the next
most significant digit and returning to 0.
NOTE: The wireless module's serial number is the same as the Bluetooth® MAC address.
4. Once connected to the Soft AP, use a web browser and enter 192.168.0.1 as the URL address and press Enter.
NOTE: Once connected to a network, a web browser on that network can connect to the Web Manager by simply navigating
to the wireless module's IP Address (available on the Status page of the Web Manager).
5. Enter the default login credentials for the Web Manager.
• Username: admin
• Password: PASSWORD
IMPORTANT: It is recommended to change default passwords to limit access and for security.
6. Press Sign in. The Web Manager loads in the browser and the Status page appears.
7. Click QuickConnect at the top of the left navigation panel.
© Rice Lake Weighing Systems ● All Rights Reserved
Wi-Fi & Bluetooth® Communications
65
