Parameter
Password Configurable passwords to secure the User and Setup menus; ensure the audit jumper (J24) is in the ON position when using
the Setup password; 999999 can be entered to overwrite either password if forgotten, overwriting the password clears
configuration and calibration settings (use Revolution to backup settings before overwriting); Sub-Parameters:
User – User menu password secures the user menu with configured password;
Setup – Setup menu password secures the setup menu with configured password;
Consecutive Number Allows sequential numbering for print operations; the value is incremented following each print operation which includes
<CN> in the ticket format; Enter value: 0–9999999, 0 (default)
Consecutive Number Specifies the initial consecutive number value used when the consecutive number is reset by sending Clear Consecutive
Number digital input; Enter value: 0–9999999, 0 (default)
Start
Unit ID Specifies the unit identification with an alphanumeric value; Enter characters: Up to 6 alphanumeric characters, 1 (default)
Contact Contact Information; See
Accumulator Accumulation can be toggled On/Off; if On, accumulation occurs on print operation; if Off, an accumulation does not occur;
Settings: Off (default), On
Weighment Threshold When the weight falls below the value set, the accumulator is rearmed; Enter value: 0.0–9999999.0, 1000.0 (default)
Number of Displays the total number of weighments (read only)
Weighments
Maximum Weight Displays the maximum weight/weighment allowed (read only)
Date of Maximum Displays the date and time the maximum weight/weighment occurred (read only)
Weight
Date Allows setting of the date format and date separator character
Date Format – Settings: MMDDYY (default), DDMMYY, YYMMDD, YYDDMM
Date Separator – Settings: Slash (default), Dash, Semi, Dot
Time Allows setting of the time format and the separator character
Time Format – Settings: 12HOUR (default), 24HOUR
Time Separator – Settings: Colon (default), Comma, Dot
Keyboard Lock Disables the keyboard except for the menu and power key; Settings: Off (default), On
Lock All Keys Disables the keyboard except for the zero, menu and power keys; Settings: Off (default), On
Except Zero
Key Hold Allows setting of the key hold time and interval
Key Hold Time – How long a key needs to be held before a key hold action is initiated (in tenths of a second);
Key Hold Interval – The amount of time between increments during a key hold (in twentieths of a second);
2 equals a tenth of a second (10 increments per second during a key hold); Enter value: 1–100, 2 (default)
Locale Enables location gravity compensation; Settings:
Off (default) – gravity compensation disabled
On – calculates gravity compensation using the origin and destination latitudes and elevations
Factor – uses origin and destination gravity factors to find gravity compensation
Origin Latitude Origin latitude (to nearest degree) for gravity compensation; displays when Locale parameter is set to On;
Enter value: 0–90, 45 (default)
Origin Elevation Origin elevation (in meters) for gravity compensation; displays when Locale parameter is set to On;
Enter value: -9999–9999, 345 (default)
Destination Latitude Destination latitude (to nearest degree) for gravity compensation; displays when Locale parameter is set to On;
Enter value: 0–90, 45 (default)
Destination Elevation Destination elevation (in meters) for gravity compensation; displays when Locale parameter is set to On;
Enter value: -9999–9999, 345 (default)
Origin Gravity
Origin gravity factor (in m/s
Enter value: 9.00000–9.99999, 9.80665 (default)
Destination Gravity
Destination gravity factor (in m/s
Enter value: 9.00000–9.99999, 9.80665 (default)
Persistent Tare Tare persists through a power cycle; Settings: Off (default), On
Remote Print Specifies if the 682 (Local) or another indicator (Remote) handles the print key; Settings: Remote (default), Local
Destination
Table 4-15. Program Menu Parameters (Continued)
Enter characters: Up to 16 alphanumeric characters
Enter characters: Up to 16 alphanumeric characters
Section 4.5.5.2 on page 45
20 equals 2 seconds; Enter value: 10–50, 20 (default)
) for gravity compensation; displays when Locale parameter is set to Factor;
2
) for gravity compensation; displays when Locale parameter is set to Factor;
2
