Parts Kit Components; Ac Models; Dc Models - Rice Lake REVOLUTION 682 Synergy Plus Technical Manual

2.8

Parts Kit Components

2.8.1

682 AC Models

Part No.
15631
15650
193230
194219
194446
19538
195993
195995
195998
202140
42149
53075
67550
75062
94422
NOTE: The recommended cable strip length is 0.25 in (7 mm) for all 682 connectors.
2.8.2

682 DC Models

Part No.
15631
15650
15888
193230
194219
194446
19538
195993
195995
195998
202140
42149
53075
67550
75062
94422
Table 2-13. AC Models Parts Kit (PN 194477)
Cable tie, 3 inch nylon
Mount, cable tie 3/4 inch
Screw, machine M4-0.7 x 10 Phillips pan head SST
Screw, machine M4-0.7 x 10 Phillips drilled cheese head SST
Ferrite core, snap on Fair-Rite 220 ohm
Post plug, slotted black plastic stem, 1/4 x 1, seals inside cord grip
Connector, 6 position screw terminal pluggable 3.50 mm black
Connector, 4 position screw terminal pluggable 3.50 mm black
Connector, 5 position screw terminal pluggable 3.50 mm black
Screw, machine M4-0.7 x 10 Phillips pan head, zinc with external tooth washer SEMS
Bumper, rubber grommet 0.50 (OD) x 0.281 (ID)
Clamp, ground cable shield, radius 0.078 inch
Clamp, ground cable shield, radius 0.125 inch
Washer, bonded sealing #8 7/16 (0.4375) OD SST
Label, capacity 0.40 x 5.00
Table 2-14. DC Models Parts Kit (PN 202065)
Cable tie, 3 inch nylon
Mount, cable tie 3/4 inch
Terminal block, 3 position
Screw, machine M4-0.7 x 10 Phillips pan head SST
Screw, machine M4-0.7 x 10 Phillips drilled cheese head SST
Ferrite core, snap on Fair-Rite 220 ohm
Post plug, slotted black plastic stem, 1/4 x 1, seals inside cord grip
Connector, 6 position screw terminal pluggable 3.50 mm black
Connector, 4 position screw terminal pluggable 3.50 mm black
Connector, 5 position screw terminal pluggable 3.50 mm black
Screw, machine M4-0.7 x 10 Phillips pan head, zinc with external tooth washer SEMS
Bumper, rubber grommet 0.50 (OD) x 0.281 (ID)
Clamp, ground cable shield, radius 0.078 inch
Clamp, ground cable shield, radius 0.125 inch
Washer, bonded sealing #8 7/16 (0.4375) OD SST
Label, capacity 0.40 x 5.00
