- Page 1 RL9000 Series ® Weigh Module Kit Models TWM & TWM-HT Installation Manual July 1, 2019 PN 89284 Rev B...
- Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
-
Page 3: Table Of Contents
5.3 250K to 450K Assembly........10 Technical training seminars are available through Rice Lake Weighing Systems. - Page 4 RL9000 Series Weigh Module Kit Visit our website www.RiceLake.com...
-
Page 5: Introduction
This manual is meant to serve only as a general guideline for installation.Each installation is unique and should be planned by a qualified structural engineer. Manuals and additional resources are available from the Rice Lake Weighing www.ricelake.com Systems website at www.ricelake.com/... -
Page 6: Safety Section
IMPORTANT General Safety Do not operate or work on this equipment unless this manual has been read and all instructions are understood. Contact any Rice Lake Weighing Systems dealer for replacement manuals. WARNING Failure to heed may result in serious injury or death. -
Page 7: Load Cell Wiring
Junction Box Connections, Adjustments and Calibration • Refer to junction box manual for trimming details. • Refer to indicator manual for system calibration details. © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 8: Troubleshooting
RL9000 Series Weigh Module Kit Troubleshooting If the system powers up and gives some type of stable digital readout that varies with the load on the system, any system problems are probably caused by factors other than the load cells. The load cells are often blamed for a malfunctioning system, but 90% of the time, the problem lies elsewhere. -
Page 9: Mechanical Installation
Protect the load cell and cable from weld splatter. Example: if welding on the mount top plate, the ground must be connected to the vessel, not to the mount base or support structure. © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 10: Weigh Module Installation
RL9000 Series Weigh Module Kit • Use only hermetically sealed load cells in wash down applications. environmentally protected load cells are not suitable for such applications and will be damaged. If tanks and surrounding equipment are frequently steam cleaned or if the load cell is subjected to direct wash down, a protective shroud for the weighing assembly is recommended. - Page 11 • Back the screw off 1/4 turn. The screw provides lateral restraint and lift off protection. Never remove it or back it off more than the suggested amount. © Rice Lake Weighing Systems ● All Rights Reserved...
-
Page 12: Dimensional Drawings
RL9000 Series Weigh Module Kit Dimensional Drawings 1K to 100K Assembly CABLE CONN. 4X F ØD 4X ØE THRU Dimensions (Inches) Rated Conduit Capacity Adapter 1K-10K 3.25 3/8-16 1.35 0.375 0.75 3.25 3/8-16 1.60 0.625 0.75 20-50K 3.75 5.50 0.63 1/2-13 2.48... -
Page 13: 150K To 200K Assembly
150K to 200K Assembly CABLE CONN. B.C. ØB2 4X F ØD 4X ØE THRU Dimensions (Inches) Rated Conduit Capacity Adapter 150K-200K 10.0 7.825 1-14 4.75 1/2-14 NPT Table 5-2. 150-200K Assembly © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 14: 250K To 450K Assembly
RL9000 Series Weigh Module Kit 250K to 450K Assembly CABLE CONN. B.C. ØB2 4X F ØD 4X ØE THRU Dimensions (Inches) Rated Conduit Capacity Adapter 250K-450K 11.0 7.75 7/8-14 6.42 2.25 1/2-14 NPT Table 5-3. 250-450K Assembly www.RiceLake.com Visit our website... - Page 16 Specifications subject to change without notice. Rice Lake Weighing Systems is an ISO 9001 registered company. 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319...
