682 Synergy Plus
1.2

FCC Compliance

United States
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Canada
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils
numériques de la Class A prescites dans le Règlement sur le brouillage radioélectrique edicté par le ministère des
Communications du Canada.
1.3

Operating Modes

Weigh Mode
Weigh mode is the default mode of the indicator. The indicator displays gross or net weights as required.
User Mode
User mode is accessible by pressing
Tare, Time, Date, MAC ID, Fieldbus Version and Version menus is available when in User mode. Access to the User menu can
be password protected (Section 3.4.22 on page
Time and Date menus.
Setup Mode
Many of the procedures described in this manual, require the indicator to be in Setup mode.
See Section 4.0 on page 29
pressing the setup switch or by pressing
Setup menu can also be password protected
NOTE: See Section 4.5.5 on page 42
1.4

Option Cards

The 682 has a single option card slot which can support the Synergy Series Option Cards. The Synergy Series Option Card kits
include instructions for installation and setup.
• Single Analog Output Option Card Kit (PN 195084)
• Relay Option Card Kit (PN 211709)
• Dual Serial Option Card Kit (PN 211710)
1.5

RJ45 Option

The 682 is available with an external RJ45 option. This external RJ45 connector is located on the backplate of the 682 and
provides quick access to Ethernet TCP/IP 10Base-T/100Base-TX communication
682 indicators without the RJ45 option access Ethernet using the J8 connector on the CPU board inside of the enclosure.
2 Visit our website
on the front panel. Access to the Audit, Calibration, limited Setpoint, Accumulator,
28). The User menu includes the Calibration, limited Setpoints, Accumulator,
for the procedure to enter Setup mode and the parameters available. Setup mode is accessible by
on the front panel when the audit jumper is in the ON position. Access to the
(Section 3.4.22 on page
for the menu location and description of the password parameters.
www.RiceLake.com
28).
(Section 2.4.11 on page 10).
