682 Synergy Plus
Parameter
Percent Relative Performs functions based on a specified percentage of the target value of a referenced setpoint,
using the same weight mode as the referenced setpoint; the actual target value of the Percent
Relative setpoint is calculated as a percentage of the target value of the referenced setpoint
Pause Pauses the batch sequence indefinitely; a Batch Start signal must be initiated to continue the
batch process
Delay Delays the batch sequence for a specified time; the length of the delay (in tenths of a second) is
specified on the Value parameter
Wait Standstill Suspends the batch sequence until the scale is at standstill
Counter Specifies the number of consecutive batch sequences to perform; place counter setpoints at the
beginning of a batch routine
Auto-Jog Automatically checks the previous weight-based setpoint to verify the setpoint weight value is
satisfied in a standstill condition
• If the previous setpoint is not satisfied when at standstill, the Auto-Jog setpoint activates
the digital output of the previous weight-based setpoint for a period of time, specified on
the Value parameter (in tenths of a second)
• The Auto-Jog process repeats until the previous weight-based setpoint is satisfied when
the scale is at standstill
NOTE: The Auto-Jog digital output is typically used to signify an Auto-Jog operation is
being performed.
NOTE: Auto-Jog uses the digital output of the previous weight-based setpoint, and
should not be assigned to the same digital output as the related weight-based setpoint.
Center of Zero Monitors for a gross center of zero condition
• The digital output associated with this setpoint kind is activated when the referenced scale
is at center of zero
• No value is required for this setpoint
In Motion Monitors for an in-motion condition
• The digital output associated with this setpoint is activated when scale is not at standstill
• No value is required for this setpoint
In Range Monitors for an in-range condition
• The digital output associated with this setpoint is activated when the scale is within
capacity range
• No value is required for this setpoint
Batch in Process Batch processing signal:
• The digital output associated with this setpoint is activated whenever a batch sequence is
in progress
• No value is required for this setpoint
Timer Tracks the progress of a batch sequence based on a timer
• The timer value, in tenths of a second, determines the length of time allowed between start
and end setpoints
• Start and End parameters are used to specify the start and end setpoints
• If the End setpoint is not reached before the timer expires, the digital output associated
with this setpoint is activated
Concurrent Allows a digital output to remain active over a specified portion of the batch sequence
• Type 1 (Value = 0): The digital output associated with this setpoint becomes active when
the Start setpoint becomes the current batch step and remains active until the End setpoint
becomes the current batch step
• Type 2 (Value > 0): If a non-zero value is specified for the Value parameter, the value
represents the timer, in tenths of a second, for this setpoint; The digital output associated
with this setpoint becomes active when the Start setpoint becomes the current batch step
and remains active until the timer expires
Time of Day Performs functions when the internal clock time of the indicator matches the specified
setpoint time
Always This setpoint is always satisfied; It is typically used to provide an endpoint for true/false
branching batch routines
Never This setpoint is never satisfied; Used to branch to a designated setpoint in true/false branching
batch routines in which the batch does not continue through the normal sequence of batch
setpoints
100 Visit our website
Table 14-1. Setpoint Kinds (Continued)
Description
www.RiceLake.com
Batch Continuous
X X
X
X
X
X
X
X
X
X
X
X
X
X X
X
X
