682 Synergy Plus
Command
REG.CTARE
REG.NEGTOTAL
REG.PRTMOT
REG.PRINTPT
REG.OVRBASE
REG.AZTNET
REG.MANUALCLEARTARE
REG.TAREINMOTION
REG.ZEROINMOTION
REG.UNDERLOAD
NTEP defaults shown for regulatory command values

12.15 Setpoint Commands

The following commands can be used to configure setpoint parameters.
Command
BATCHNG Batching mode
SP.KIND#n Setpoint kind
SP.VALUE#n Setpoint value
SP.TRIP#n Trip
SP.BANDVAL#n Band value
SP.HYSTER#n Hysteresis
SP.PREACT#n Preact type
SP.PREVAL#n Preact value
SP.PREADJ#n Preact adjustment percentage
SP.PRESTAB#n Preact learn stability (in tenths of a second)
SP.PCOUNT#n Preact learn interval
SP.BATCH#n Batch step enable
SP.CLRACCM#n Clear accumulator enable
SP.CLRTARE#n Clear tare enable
SP.PSHACCM#n Push accumulate
SP.PSHPRINT#n Push print
SP.PSHTARE#n Push tare
SP.ALARM#n Alarm enable
SP.ALIAS#n Setpoint name
SP.ACCESS#n Setpoint access
SP.DSLOT#n Digital output slot
SP.DIGOUT#n Digital output
SP.SENSE#n Digital output sense
SP.BRANCH#n Branch destination (0 = do not branch)
SP.RELNUM#n Relative setpoint number
SP.START#n Starting setpoint
SP.END#n Ending setpoint
SP.TIME#n Trip time
SP.DURATION#n Trip duration
SP.ENABLE#n Setpoint enable
For setpoint commands ending with #n, n is the setpoint number (1-8)
92 Visit our website
Table 12-14. Regulatory Commands (Continued)
Description
Allow Clear key to clear tare/accumulator
Allow total scale to display negative value
Allow print while in motion
Add PT to keyed tare print
Zero base for overload calculation
Perform AZT on Net value
Allows manual clearing of the tare value
Allows Tare in Motion
Allows scale to be zeroed while in motion
Underload weight value in display divisions
Table 12-15. Setpoints Commands
Description
www.RiceLake.com
NO, YES (default)
NO (default), YES
NO (default), YES
NO, YES (default)
CALIB (default), SCALE
NO (default), YES
NO, YES (default)
NO (default), YES
NO (default), YES
1–9999999, 20 (default)
OFF (default), AUTO, MANUAL
OFF (default), GROSS, NET, -GROSS, -NET, ACCUM, POSREL, NEGREL,
PCTREL, PAUSE, DELAY, WAITSS, COUNTER, AUTOJOG, COZ, INMOTON,
INRANGE, BATCHPR, TIMER, CONCUR, TOD, ALWAYS, NEVER
0.0–9999999.0, 0.0 (default)
HIGHER (default), LOWER, INBAND, OUTBAND
0.0–9999999.0, 0.0 (default)
0.0–9999999.0, 0.0 (default)
OFF (default), ON, LEARN
0.0–9999999.0, 0.0 (default)
0.0–100.0, 50.0 (default)
0–65535, 0 (default)
1–65535, 1 (default)
OFF (default), ON
OFF (default), ON
OFF (default), ON
OFF (default), ON, ONQUIET
OFF (default), ON, WAITSS
OFF (default), ON
OFF (default), ON
Up to 8 alphanumeric characters, SETPT (default)
OFF, ON (default), HIDE
NONE (default), 0
1–4, 1 (default)
NORMAL (default), INVERT
0–8, 0 (default)
1–8, 1 (default)
1–8, 1 (default)
1–8, 1 (default)
hhmm, 0000 (default)
hhmmss, 000000 (default)
OFF, ON (default)
Values
Values
