Parameter
Preact Count Setpoints with Preact set to Learn, specifies the number of batches after which the preact value is recalculated; the default value, 1,
recalculates the preact value after every batch cycle; Enter value: 1–65535, 1 (default)
Relative For relative setpoints, specifies the number of the relative setpoint; Enter value: 1–8, 1 (default)
Setpoint
Target weight for this setpoint is determined as follows:
Number
Positive Relative setpoints, the value of the relative setpoint plus the value (Value parameter) of the Positive Relative setpoint
Negative Relative setpoints, the value of the relative setpoint minus the value of the Negative Relative setpoint
Percent Relative setpoints, the percentage (specified on Value parameter of the Percent Relative setpoint) of the target value of the
relative setpoint
Alarm Specify On to display the word Alarm on the primary display while the setpoint is active (batch setpoints) or while the setpoint is not
tripped (continuous setpoints); Settings: Off (default), On
Specify On to clear the accumulator when the setpoint is satisfied; Settings: Off (default), On
Clear
Accumulator
Specify On to clear the tare when the setpoint is satisfied; Settings: Off (default), On
Clear Tare
Push Specify On to update the accumulator and perform a print operation when the setpoint is satisfied; specify On Quiet to update the
accumulator without printing; Settings: Off (default), On, On Quiet
Accumulator
Push Print Specify On to perform a print operation when the setpoint is satisfied; specify Wait Standstill to wait for standstill after setpoint is satisfied
before printing; Settings: Off (default), On, Wait Standstill
Push Tare Specify On to perform an acquire tare operation when the setpoint is satisfied; Settings: Off (default), On
NOTE: Push Tare acquires the tare regardless of the value specified for the Regulatory Mode parameter in the Program menu
Digital Output Lists all available digital I/O slots; this parameter specifies the slot number of the digital I/O card referenced by the Digital Output setpoint;
Slot Settings: None (default), 0, 1
Digital Output Lists all digital output bit numbers available for the specified Digital Output Slot; this parameter is used to specify the digital output bit
associated with this setpoint; use the Digital I/O menu to assign bit function to Output; Enter value: 1–4, 1 (default)
NOTE: For continuous setpoints, the digital output becomes active (low) when the condition is met; for batch setpoints, the digital output is
active until the setpoint condition is met
Sense Specifies whether the value of the digital output associated with this setpoint is inverted when the setpoint is satisfied;
Settings: Normal (default), Invert
Batch Specifies whether the setpoint is used as a batch (On) or continuous (Off) setpoint; Settings: Off (default), On
Branch Specifies the setpoint number to which the batch sequence is to branch, if the current setpoint is not satisfied upon initial evaluation
(0 = do not branch); Enter value: 0–8, 0 (default)
Specifies if setpoint parameters display in User mode; Settings: On (default), Off
Enable
Access Specifies the access allowed to setpoint parameters in User mode; Settings:
On (default) – Values can be displayed and changed
HIDE – Values cannot be displayed or changed
OFF – Values can be displayed but not changed
Alias Name for the setpoint; Enter characters: Alphanumeric entry up to 8 characters, SETPT# (default)
Table 4-21. Kind Parameter Descriptions (Continued)
Description
