2.2 Product specification

Function
Input voltage (V)
Power
Allowable Voltage
input
Input current (A)
Output voltage (V)
Output current (A)
Power
Output power (kW)
output
Output frequency
Adjustable-speed
Technical
control
Speed fluctuation
feature
Torque response
Frequency setting
Running
control
Auto-adjustment of
feature
Peripheral
interface
Fluctuation
Input frequency
(Hz)
(Hz)
Control mode
ratio
Speed control
accuracy
Torque control
accuracy
Starting torque
method
the voltage
Fault protection
Analog input
Analog output
AC 1PH 110V–120V;
AC 1PH 200V–240V;
AC 3PH 200V–240V;
AC 3PH 380V–480V
-15%–+10%
Refer to section 2.5 "Rated specifications"
50Hz or 60Hz; allowed range: 47–63Hz
0–input voltage (S12 model: 0–240)
Refer to section 2.5 "Rated specifications"
Refer to section 2.5 "Rated specifications"
0–400Hz
SVPWM, SVC
Asynchronous motor 1: 100 (SVC)
± 0.2% (SVC)
± 0.3% (SVC)
<20ms (SVC)
10%
0. 5Hz/150% (SVC)
Digital setting, analog setting, pulse frequency
setting, multi-step speed running setting, simple
PLC setting, PID setting, Modbus communication
setting
Shift between the set combination and set channel.
Keep a stable voltage automatically when the grid
voltage transients
Provide comprehensive fault protection functions:
overcurrent, overvoltage, undervoltage, overheating,
phase loss and overload, etc.
1 input (AI2): 0–10V/0–20mA; 1 input (AI3): -10–10V
2 inputs (AO1, AO2): 0–10V/0–20mA
