Goodrive20-UL Series VFD
Function
SW 1 of the VFD
SW 1 of the VFD
Fault code of the
VFD
Identifying code
of the VFD
Operation
frequency
Address
Bit5: =1 DC braking
braking prohibition
Virtual input terminal command, range:
200AH
0x000–0x1FF
Virtual output terminal command, range:
200BH
0x00–0x0F
Voltage setting value (special for V/F
separation)
200CH
(0–1000,
100.0% of the rated voltage of the motor)
AO output setting 1
(-1000–1000,
200DH
100.0%)
AO output setting 2
(-1000–1000,
200EH
100.0%)
0001H: Forward running
0002H: Forward running
0003H: Stop
2100H
0004H: Fault
0005H: POFF state
0006H: Pre-exciting state
Bit0: =0: bus voltage is not established
=1: bus voltage is established
Bit1–2: =00: motor 1
Bit3: =0: asynchronous motor
2101H =1: synchronous motor
Bit4: =0: pre-alarm without overload
=1: overload pre-alarm
Bit5–Bit6: =00: keypad control
See the fault type instruction
2102H
GD20-UL-----0x0106
2103H
3000H 0–Fmax, unit: 0.01Hz
Data description
1000 corresponds
1000 corresponds
1000 corresponds
=01: motor 2
=10: motor 3 =11: motor 4
=01: terminal control
=10: communication control
Compatible with
the
-126-
Communication protocol
R/W
characteristics
=0: DC
R/W
R/W
R/W
to the
to
R/W
to
R/W
R
R
R
R
R
