Function
Name
code
Vibration
P04.12 control
threshold
Energy-sa
ving
P04.26
operation
selection
Voltage
Setting
P04.27
channel
Keypad
P04.28 setting
voltage
Voltage
P04.29 increasing
time
Voltage
P04.30 decreasing
time
Output
P04.31 maximum
voltage
Output
P04.32 minimum
voltage
Description
0: No operation
1: Automatic energy-saving operation
Motor on the light load conditions, automatically
adjusts the output voltage to save energy
Select the output setting channel at V/F curve
separation.
0: Keypad setting voltage: the output voltage is
determined by P04.28.
1: AI1 setting voltage
2: AI2 setting voltage
3: AI3 setting voltage
4: HDI setting voltage
5: Multi-step speed setting voltage;
6: PID setting voltage;
7: Modbus communication setting voltage;
8–10: Reversed
Note: 100% corresponds to the rated voltage of
the motor.
The function code is the voltage digital set value
when the voltage setting channel is selected as
"keypad selection".
Setting range: 0.0%–100.0%
Voltage increasing time is the time when the
VFD accelerates from the output minimum
voltage to the output maximum voltage.
Voltage decreasing time is the time when the
VFD decelerates from the output maximum
voltage to the output minimum voltage.
Setting range: 0.0–3600.0s
Set the upper and low limit of the output voltage.
Setting range of P04.31: P04.32–100.0%
(the rated voltage of the motor)
Setting range of P04.32: 0.0%– P04.31
(the rated voltage of the motor)
-51-
Function parameters
Default Modify
○
30.00 Hz
◎
0
○
0
○
100.0%
○
5.0s
○
5.0s
◎
100.0%
◎
0.0%
