INVT Goodrive20-UL VFD Series Operation Manual page 34

Goodrive20-UL Series VFD
Function
Name
code
Upper
limit of the
P00.04
running
frequency
Lower
limit of the
P00.05
running
frequency
A
frequency
P00.06
command
selection
B
frequency
P00.07
command
selection
Description
The upper limit of the running frequency is the
upper limit of the output frequency of the VFD
which is lower than or equal to the maximum
frequency.
Setting range: P00.05–P00.03 (Max. output
frequency)
The lower limit of the running frequency is that
of the output frequency of the VFD.
The VFD runs at the lower limit frequency if the
set frequency is lower than the lower limit.
Note: Max. output frequency ≥ Upper limit
frequency ≥ Lower limit frequency
Setting range: 0.00Hz–P00.04 (Upper limit of
the running frequency)
0: Keypad data setting
Modify the value of function code P00.10 (set
the frequency by keypad) to modify the
frequency by the keypad.
1: Analog AI1 setting (corresponding keypad
potentiometer)
2: Analog AI2 setting (corresponding terminal
AI2)
3: Analog AI3 setting (corresponding terminal
AI3)
Set the frequency by analog input terminals.
Goodrive20-UL series VFDs provide 3 channels
analog input terminals
configuration, of which AI1 is adjusting through
analog potentiometer,
voltage/current option (0–10V/0–20mA) which
can be shifted by jumpers; while AI3 is voltage
input (-10V–+10V).
Note: When analog AI2 select 0–20mA input,
the corresponding voltage of 20mA is 10V.
100.0% of the analog input setting corresponds
to the maximum frequency (function code
P00.03) in forward direction and -100.0%
corresponds to the maximum frequency in
as the
while AI2
-29-
Function parameters
Default
60.00Hz
0.00Hz
0
standard
2
is the
Modify
◎
◎
○
○
