Goodrive20-UL Series VFD
Function
Name
code
Self-defined
address of
P14.07
the running
command
Self-defined
address of
P14.08
frequency
setting

P17 group Status viewing

Function
Name
code
Setting
P17.00
frequency
Output
P17.01
frequency
Ramp
P17.02 reference
frequency
Output
P17.03
voltage
Output
P17.04
current
P17.05 Motor speed
Torque
P17.06
current
Magnetized
P17.07
current
Description
upper monitor. The communication efficiency
can be increased in this mode.
Tens place: Communication encryption
0: Disabled
1: Enabled
Hundreds place:
communication command address
0: Disabled
1: Enabled
0x0000–0xffff
0x0000–0xffff
Description
Display current set frequency of the VFD
Range: 0.00Hz–P00.03
Display current output frequency of the VFD
Range: 0.00Hz–P00.03
Display current ramp reference frequency of
the VFD
Range: 0.00Hz–P00.03
Display current output voltage of the VFD
Range: 0–1200V
Display current output current of the VFD
Range: 0.0–5000.0A
Display the rotation speed of the motor.
Range: 0–65535RPM
Display current torque current of the VFD
Range: 0.0–5000.0A
Display current magnetized current of the
VFD
-97-
Self-define the
Function parameters
Default Modify
○
0x1000
○
0x2000
Default Modify
●
●
●
●
●
●
●
●
