Goodrive20-UL Series VFD
Function
Name
code
P17.23 reference
value
PID feedback
P17.24
value
Power factor
P17.25
of the motor
Current
P17.26
running time
Simple PLC
and the
current stage
P17.27
of the
multi-step
speed
ASR
P17.28 controller
output
Magnetic flux
P17.32
linkage
Exciting
P17.33 current
reference
Torque
P17.34 current
reference
AC input
P17.35
current
Output
P17.36
torque
Motor
P17.37 overload
counting
PID
Display PID reference value
Range: -100.0–100.0%
Display PID feedback value
Range: -100.0–100.0%
Display the current power factor of the motor.
Range: -1.00–1.00
Display the current running time of the VFD.
Range: 0–65535min
Display simple PLC and the current stage of
the multi-step speed
Range: 0–15
The percentage of the rated torque of the
relative motor, display ASR controller output
Range: -300.0%–300.0% (the rated motor
current)
Display the magnetic flux linkage of the
motor.
Range: 0.0%–200.0%
Display the exciting current reference in the
vector control mode.
Range: -3000.0–3000.0A
Display the torque current reference in the
vector control mode.
Range: -3000.0–3000.0A
Display the input current in AC side.
Range: 0.0–5000.0A
Display the output torque. Positive value is in
the electromotion state, and negative value
is in the power generating state.
Range: -3000.0Nm–3000.0Nm
0–100 (Display the "OL1" fault when the
count value is 100)
Description
-99-
Function parameters
Default Modify
●
●
●
●
●
●
●
●
●
●
●
●
