INVT Goodrive20-UL VFD Series Operation Manual page 67

Goodrive20-UL Series VFD
Function
Name
code
Lower
limit of
P06.17
AO1
output
Correspo
nding
AO1
P06.18
output to
the lower
limit
Upper
limit of
P06.19
AO1
output
The
correspon
ding AO1
P06.20
output to
the upper
limit
Description
voltage of the VFD)
7: Output power (relative to twice the rated
power of the motor)
8: Set torque value (relative to twice the rated
torque of the motor)
9: Output torque (relative to twice the rated
torque of the motor)
10: Analog AI1 input value
11: Analog AI2 input value
12: Analog AI3 input value
13: High speed pulse HDI input value
14: Modbus communication set value 1
15: Modbus communication set value 2
16–21: Reserved
22: Torque current (corresponds to 3 times
rated current of the motor)
23: Ramp reference frequency (with sign)
24–30: Reserved
The above function codes define the relative
relationship between the output value and
analog output. When the output value exceeds
the range of set maximum or minimum output, it
will count according
upper-limit output.
When the analog output is current output, 1mA
equals to 0.5V.
In different cases, the corresponding analog
output of 100% of the output value is different.
For detailed information, please refer to analog
output instructions in Chapter 7.
AO 10V (20mA)
0.0%
Setting range of P06.17: -100.0%– P06.19
Setting range of P06.18: 0.00V–10.00V
to the low-limit
100.0%
-62-
Function parameters
Default Modify
○
0.0%
or
○
0.00V
○
100.0%
○
10.00V
