Goodrive20-UL Series VFD
Function
Name
code
FDT2
retention
P08.35
detection
value
Frequency
arrival
P08.36
detection
range
Energy
P08.37 Braking
enable
Description
Output frequency
FDT electrical level
Y, RO1, RO2
Setting range of P08.32: 0.00Hz–P00.03 (Max.
output frequency)
Setting range
0.0–100.0%
Setting range of P08.34: 0.00Hz–P00.03 (Max.
output frequency)
When the output frequency is among the below
or above range of the set frequency, the
multi-function digital output terminal will output
the signal of "frequency arrival", see the
diagram below for detailed information:
Output frequency
Set frequency
,
Y
RO1, RO2
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
This parameter is used to control the internal
braking unit.
0: Disabled
1: Enabled
Note: It is only applicable to VFD models that
are built in braking units.
FDT retention
of P08.33 and
Detectionn range
Time
Time
-76-
Function parameters
Default
Time
5.0%
Time
P08.35:
0.00Hz
0
Modify
○
○
○
