Goodrive20-UL Series VFD
Function
Name
code
B
frequency
P00.08 command
reference
selection
Combinati
on of the
P00.09
setting
source
Keypad
P00.10 set
frequency
Description
control when P00.06=7 or P00.07=7. It is
necessary to set P09. The running frequency of
the VFD is the value after PID effect. See P09
for the detailed information of the preset source,
preset value and feedback source of PID.
8: Modbus communication setting
The frequency
communication.
information.
9–11: Reserved
Note: A frequency and B frequency can not set
as the same frequency reference method.
0: Maximum output frequency, 100% of B
frequency setting
maximum output frequency
1: A frequency command, 100% of B frequency
setting corresponds to the maximum output
frequency. Select this setting if it needs to adjust
on the base of A frequency command.
0: A, the current frequency setting is A
frequency command
1: B, the current frequency setting is B
frequency command
2: A+B, the current frequency setting is A
frequency command + B frequency command
3: A-B, the current frequency setting is A
frequency command - B frequency command
4: Max (A, B): The bigger one between A
frequency command and B frequency is the set
frequency.
5: Min (A, B): The lower one between A
frequency command and B frequency is the set
frequency.
Note: The combination manner can be shifted
by P05 (terminal function)
When A and B frequency commands are
selected as "keypad setting", this parameter will
be the initial value of VFD reference frequency.
is set by
See P14 for
corresponds
-31-
Function parameters
Default
Modbus
detailed
to the
0
0
60.00Hz
Modify
○
○
○
