Goodrive20-UL Series VFD
Function
Name
code
HDI
frequency
P05.54
input filter
time

P06 group Output terminals

Function
Name
code
Y1 output
P06.01
selection
Relay
RO1
P06.03
output
selection
Relay
RO2
P06.04
output
selection
Description
0.000s–10.000s
Description
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: The VFD fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: In zero-speed operation (output in running
state)
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-alarm
15: Underload pre-alarm
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Setting count value arrival
19: Defined count value arrival
20: External fault valid
21: Zero-speed output (output in both running
and stopping states)
22: Running time arrival
23: Modbus communication virtual terminals
output
24–25: Reserved
26: Establishment of DC bus voltage
27–30: Reserved
-60-
Function parameters
Default Modify
○
0.100s
Default Modify
○
0
○
1
○
5
