INVT Goodrive20-UL VFD Series Operation Manual page 13

Goodrive20-UL Series VFD Product overview
Function Specification
4 common inputs, max. frequency: 1kHz;
Digital input
1 high speed input, max. frequency: 50kHz
Digital output 1 Y1 terminal output; 2 programmable relay outputs
2 programmable relay outputs
RO1A NO, RO1B NC, RO1C common terminal
Relay output
RO2A NO, RO2B NC, RO2C common terminal
Contact capacity: 3A/AC250V, 1A/DC30V
Mountable method Wall and rail mountable
Temperature of the
running -10–50° C, derate above 40° C
environment
Note:
1. The VFD with plastic casing should be installed in
Protective degree metal distribution cabinet, which conforms to IP20
and of which the top conforms to IP3X.
2. Install device in pollution degree 2 environment
Cooling mode Forced air cooling
Braking unit Embedded
Optional filter: meet the degree requirement of IEC
EMI filter
61800-3 C2, IEC 61800-3 C3
Safety Meet the requirements of CE, UL and CUL
Others
1PH&3PH 240V: Used in Canada only: "Transient
surge suppression shall be installed on the line side
of this equipment and shall be rated 240V (phase to
ground), 240V (phase to phase), suitable for
overvoltage category III, and shall provide protection
for a rated impulse withstand voltage peak of 4kV"
Overvoltage or equivalent.
category 3PH: Used in Canada only: "Transient surge
suppression shall be installed on the line side of this
equipment and shall be rated 480V (phase to
ground), 480V (phase to phase), suitable for
overvoltage category III, and shall provide protection
for a rated impulse withstand voltage peak of 6kV"
or equivalent.
-8-
