INVT Goodrive20-UL VFD Series Operation Manual page 96

Goodrive20-UL Series VFD
Function
Name
code
Overvoltage
P11.03
protection
Overvoltage
P11.04
protection
voltage
Current limit
P11.05
action
Automatic
P11.06 current limit
level
decreasing
P11.07
ratio during
current limit
0: Disabled
1: Enabled
Output
current
Overvoltage
small point
stall
Output
frequency
110–150% (standard bus voltage) (460V)
stall
110–150% (standard bus voltage) (220V)
110–130% (standard bus voltage) (110V)
The actual increasing ratio is less than the
ratio of output frequency because of the big
load during ACC running. It is necessary to
take measures to avoid overcurrent fault and
the VFD trips.
During the running of the VFD, this function
will detect the output current and compare it
with the limit level defined in P11.06. If it
exceeds the level, the VFD will run at stable
frequency in ACC running, or the VFD will
derate to run during the constant running. If it
exceeds the level continuously, the output
frequency will keep on decreasing to the
lower limit. If the output current is detected to
The
be lower than the limit level, the VFD will
accelerate to run.
Output current
Limit point
Output frequency
Set frequency
Setting range of P11.05:
0: current limit invalid
1: current limit valid
Description
Constant
ACC
speed
-91-
Function parameters
Default
1
Time
Time
120%
120%
125%
0x01
160.0%
10.00
Hz/s
Time
Time
Modify
○
○
◎
◎
◎
