Goodrive20-UL Series VFD
Function
Name
code
S5
terminals
P05.05
function
selection
S6
terminals
P05.06
function
selection
S7
terminals
P05.07
function
selection
S8
terminals
P05.08
function
selection
HDI
terminals
P05.09
function
selection
Description
13: Shift between A setting and B setting
14: Shift between combination setting and A
setting
15: Shift between combination setting and B
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi- stage speed terminal 4
20: Multi- stage speed pause
21: ACC/DEC time 1
22: ACC/DEC time 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Traverse Pause (stop at the current
frequency)
27: Traverse reset (return to the center
frequency)
28: Counter reset
29: Torque control prohibition
30: ACC/DEC prohibition
31: Counter trigger
32: Reserve
33: Cancel the frequency change setting
temporarily
34: DC brake
35: Reserve
36: Shift the command to the keypad
37: Shift the command to the terminals
38: Shift the command to the communication
39: Pre-magnetized command
40: Clear the power
41: Keep the power
42: Emergency stop
43–60: Reserved
61: PID pole switching
62–63: Reserved
-53-
Function parameters
Default Modify
◎
0
◎
0
◎
0
◎
0
◎
0
