INVT Goodrive20-UL VFD Series Operation Manual page 73

Goodrive20-UL Series VFD
Function
Name
code
Factory
P07.23
bar code 3
Factory
P07.24
bar code 4
Factory
P07.25
bar code 5
Factory
P07.26
bar code 6
Current
P07.27
fault type
Previous
P07.28
fault type
Previous 2
P07.29
fault type
Previous 3
P07.30
fault type
Previous 4
P07.31
fault type
Previous 5
P07.32
fault type
Description
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0: No fault
1: Inverter unit U phase protection (OUt1)
2: Inverter unit V phase protection (OUt2)
3: Inverter unit W phase protection (OUt3)
4: Overcurrent during acceleration (OC1)
5: Overcurrent during deceleration (OC2)
6: Overcurrent during constant speed running
(OC3)
7: Overvoltage during acceleration (OV1)
8: Overvoltage during deceleration (OV2)
9: Overvoltage during constant speed running
(OV3)
10: Bus undervoltage (UV)
11: Motor overload (OL1)
12: VFD overload (OL2)
13: Phase loss on input side (SPI)
14: Phase loss on output side (SPO)
15: Rectifier module overheat (OH1)
16: Inverter module overheat (OH2)
17: External fault (EF)
18: 485 communication fault (CE)
19: Current detection fault (ItE)
20: Motor antotuning fault (tE)
21: EEPROM operation fault (EEP)
22: PID feedback offline fault (PIDE)
23: Braking unit fault (bCE)
24: Running time reached (END)
25: Electronic overload (OL3)
26: Keypad communication error (PCE)
27: Parameter upload error (UPE)
28: Parameter download error (DNE)
-68-
Function parameters
Default Modify
●
●
●
●
●
●
●
●
●
●
