4 .3 .2 Y- a x i s
1
Fig.7: Y-axis
1. Reference switch, inductive
2. Reference Aktivator
3. Mechanical end stop
Fig.7.2: Rear Y-axis (bridge)
The servo motor with gearbox of the Y-axis can be found behind the sheet metal of the Z-
1.
axis
Energy cable chain
2.
Central lubrication – oil tank with pump
3.
CNC-STEP GmbH & Co. KG ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
3
4
1
2
Operating instructions
2
Fig.7.1: Y-axis
4. Rack
5. Linear Guide
3
T-Rex Servo-Series
5
