Location of the emergency stop buttons
The EMERGENCY stop switch (Fig.2/2) is located at the terminal directly next to the touch panel.
The main switch (Fig.2/1) also serves as an EMERGENCY stop switch. This is only rotated and
switches off the machine completely.
Fig.2: Operator terminal
CNC-STEP GmbH & Co. KG ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
1 Main switch
2 Emergency stop button
2
1
