4 .4 O p e r a t o r t e r mi n a l
The machine has a control element via which all functions are called and the
Movement of the machine is controlled.
In addition to the actual machine control, the terminal contains an industrial PC with touch
screen and the KinetiC-NC control software.
Fig.10: Operator terminal
CNC-STEP GmbH & Co. KG ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
5
1
1 - Main switch
2
2 - Emergency stop button
3
3 - Control On (Reset)
4
4 - Vacuum pump(s) on/off
5 - Industrial PC
6
6 - USB-Connectors
