Brief description
The machine includes the complete mechanics for a three-dimensional movement. The linear
movement of the slides takes place via gear drives in X and Y and ball screws in the Z-axis, driven
by Servo motors. The Servo motors for the process of the individual axes are controlled via further
interfaces.
This operating manual describes the installation, commissioning, and maintenance of the CNC
gantry system.
This guide refers to the T-Rex servo series in the standard configuration with a 3.5KW HF
spindle from HQD.
There are many other options available, which are then described in separate instructions.
