Technical Specifications; General Information - CNC-Step T-Rex Servo Series Operating Instructions Manual

Technica l specifica tio ns
3
3 .1 G e n e r a l i n f o r ma t i o n
Machine
Specification
Length (L)
Width (W)
Height (H) Standard
Z-axis 300mm (Opt.)
Z-axis 400mm (Opt.)
Weight
Clamping Area (L xW)
Passage height
Standard
Z-axis 300mm (Opt.)
Z-axis 400mm (Opt.)
Passage height
measured
Load capacity Z-axis
attachment weight
CNC-STEP GmbH & Co. KG ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
T-Rex 0609 T-Rex 0615
1650 mm 2250 mm
1440 mm 1440 mm
2050 mm 2050 mm
2400 mm 2400 mm
2850 mm 2850 mm
approx. 350
approx. 500 kg approx. 700 kg
kg
930x630mm 1530x630mm 1230x1320mm 1830x1320mm
220 mm 220 mm
320 mm 320 mm
420mm 420 mm
Lower edge bridge to the vacuum table - without accessories!
25 KG
Operating instructions
Fig.3: Machine T-Rex
T-Rex 1212
1970 mm
2150 mm
2050 mm
2400 mm
2850 mm
220 mm
320 mm
420 mm
25 KG 35 KG
T-Rex Servo-Series
Z
Y
n
d
T-Rex 1218
2570 mm
2150 mm
2050 mm
2400 mm
2850 mm
approx. 1000
kg
220 mm
320 mm
420mm
35 KG
Page 29
23.09.2020
X
