CNC-Step T-Rex Servo Series Operating Instructions Manual page 31

Y-axis
Z-axis
(200 mm is standard)
Other Parameters
Specification
Positioning Speed
1
(Rapid XY)
Working Speed (XY)
Positioning Speed
(Rapid Z)
Module size rack X/Y
axis
Steps per mm
Programmable
resolution X/Y
Ball Screw
Z-axis
Slope
Steps per mm
Programmable
resolution Z
Steps/U at
1/10-step control
Linear guides
X /Y/Z axis
Repeatability
Backlash
Servo drive
1
Measured in diagonal travel X+Y (depending on the contour shape)
CNC-STEP GmbH & Co. KG ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
1300 mm 1500 mm
200/300/400 200/300/400
mm
T-Rex 0609 T-Rex 0615
50m/min 50m/min
33m/min 33m/min
12m/min 12m/min
1,25
ca. 800 ca. 800
approx. approx.
0.00125mm 0.00125mm
Ø25mm Ø25mm
10mm
1000
0,001mm 0,001mm
10000
20mm
0,01mm 0,01mm
+- 0,015mm +- 0,015mm
400Watts 400Watts
Operating instructions
2000 mm
200/300/400
mm mm
T-Rex 1212
50m/min
33m/min
12m/min
1,25 1,25
ca. 800
approx.
0.00125mm
Ø25mm
10mm 10mm
1000 1000
0,001mm
10000 10000
20mm 20mm
0,01mm
+- 0,015mm
750Watts
T-Rex Servo-Series
2000 mm
200/300/400
mm
T-Rex 1218
50m/min
33m/min
12m/min
1,25
ca. 800
approx.
0.00125mm
Ø25mm
10mm
1000
0,001mm
10000
20mm
0,01mm
+- 0,015mm
750Watts
Page 31
23.09.2020
