CNC-Step T-Rex Servo Series Operating Instructions Manual page 55

2
4
Fig. 16.1: Nozzle unit and nozzle
The amount of air and lubricant can be adjusted via the regulating valves.
The nozzle is flexible and should be brought as close to the tool as possible.
!!! Please refer to the separate user manual for this system!!!
CNC-STEP GmbH & Co. KG ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
1. Air / Lube mixture head
2. Regulating Valve Air
3 3. Regulating Valve Lubrication
4. Spray nozzle
1
Operating instructions
T-Rex Servo-Series
Page 55
23.09.2020
