Connections On The Terminal - CNC-Step T-Rex Servo Series Operating Instructions Manual

4 .4 .2 C o n n e c t i o n s o n t h e Te r mi n a l
On the back of the Terminal, you will find the other connections to the machine.
Additional inputs and outputs (24V DC) can be connected directly to the motherboard inside the
Terminal.
1
2
Fig.10.3: Rear panel control
*Attention:
The LAN connection for integrating the machine into the company's network or the Internet can
only be used if a network switch has been ordered for the machine. This is then installed and
connected in the controller.
CNC-STEP GmbH & Co. KG ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
1 - Connection 4. Axis
2 - Connection safety fence
4
3 - Connection possibility network (LAN) *
4 - Connection vacuum pump(s) (on / off)
5 – Power Source 380V (32A)
3 5
