7 .3 T u r n o n
Staff : Operator
1 Turn on the terminal via the main switch and start the software.
2 Connect the required accessories to the power supply provided for this purpose.
3 Clamping the workpiece
4
Make sure that the required tool is in the tool holder, change tools, if necessary, see
separate operating instructions of the accessory.
5 Ensure that there are no tools or other foreign objects in the machine or plant.
6 Ensure that there are no people in the danger zone.
7 Carry out the reference trip (see note! )
8 Workpiece Offset
9 Start job.
Homing
When the machine is switched on, a homing must first be carried out. The reference switch runs
over the reference flag and determines the reference point (zero point) of the individual axes.
After the reference run has been carried out, the machine is ready for use and can be moved.
HINT:
Reference switches are required for axes without absolute position sensors
in order to have a known reference point (zero point of the axis) when
initializing the axis. From this position, all other positions are then calculated
relatively for the method of the axis via software.
